AN5560 50/60Hz identification integrated circuit

Published:2011/8/23 22:37:00 Author: | Keyword: 50/60Hz, identification, integrated circuit | From:SeekIC

The AN5560 is designed as the 50/60Hz identification integrated circuit that is produced by the Panasonic company, and it can be used in the large-screen multi-system picture in picture color TVs as the field frequency identification device. 1.Features The AN5560 is composed of the sub-screen horizontal and vertical sync signal processing circuit, the 50/60HZ field frequency identification processing circuit. And this IC uses the single row 7-pin package, the pin function and data are as shwon in table 1-20.
