CELL_GROWTH_MICROPHOTOMETER

Published:2009/7/20 11:35:00 Author:Jessie | From:SeekIC

Permits direct measurement of transmittance while stained cells are studied visually at magnification of 1,000 X. Beam-splitting mirror sends 90% of light to multiplier phototube. Maximum current sensitivity is 0.01 microamp full scale.-E. Gordy, Microphotometer Aids Biologists, Electronics, 32:28, p 62-64.
