SYNC_SIGNAL_DISTRIBUTOR

Published:2009/7/20 0:01:00 Author:Jessie | From:SeekIC

Integrate d circult on two chips distributes synchronizing signal to many television cameras in studio. Delay circuit may be added if needed. Emitter-follower output stage uses Darlington connection for maximum input impedance, while chip for output section (right) uses Darlington to obtain high d-c current gain.-Y. Tarui, Japan Seeks its Own Route lo Improved IC Techniques, Electronics, 38:25, p 90-98.
