IC_VCO_with_sawtooth_and_pulse_outputs

Published:2009/7/25 4:11:00 Author:Jessie | From:SeekIC

This circuit is similar to that of Fig. 5-36, except that simultaneous triangle and square outputs are available. The duty cycle of the outputs is controlled by R2/R3, while the frequency is set by C, R2/R3, as shown by the equations. See Conditions in Fig. 5-36B.
