General_purpose_amplifier_with_FET_AGO_circuit

Published:2009/7/21 2:27:00 Author:Jessie | From:SeekIC

Voltage offset null circuit using an ECG915 operational amplifier. See basing diagram for supply connections. Supply is ±15 volts (courtesy GTE Sylvania Incorporated)
