FERRITE_CUP_TUNER

Published:2009/7/23 21:46:00 Author:Jessie | From:SeekIC

Rotary-axial tuner consists of two pairs of ferrite cups with ground D-shaped center cores, ganged to produce linear frequency variation from 500 to 1,600 kc with 270℃ rotation, Operating frequencies can be extended to 15 Mc.-E. A. Abbot and M. Lafer, Miniature Ferrite Tuner Covers Broadcast Band, Electronics, 31;9, p 72-73.
