SN75365 Four TTL-MOS Driver Circuit

Published:2011/4/26 9:00:00 Author:TaoXi | Keyword: Four, TTL-MOS Driver | From:SeekIC

The SN75365 is one kind of TTL-MOS driver that has four NAND functions, this device is the connector between TTL circuits and high current or high voltage systems, so it drives the large capacitive loads andcan be usedwith a variety of common-MOS or RAM device. Also this device has the high-conversion speed, low power consumption, and each two drives have two public enable input pins, and the SN75365 has standard bipolar and MOS-circuit power supply. The wiring diagram of the SN75365 of type 4062 P-channel MOS RAMis as shown.
