Music controlling circuit diagram

Published:2011/8/31 2:46:00 Author:Rebekka | Keyword: Music controlling circuit | From:SeekIC

The circuit can drive 10 pieces of 40W fluorescent lamps. When K2 is closed, the brightness of the light will change the audio signal amplitude.Because fluorescent lamp has not the time delay effect like incandescent lamp, the music can control the light of dance hall accurately and timely.
