FAST_ACTION_AT_10_KC

Published:2009/7/24 4:03:00 Author:Jessie | From:SeekIC

Reverse bias is applied to gate of scr at cutoff to make switch open rapidly. Rise time is 10 microsec and fall time 5 microsec for switching 10 ma at up to 10 kc.-E. L. Dosch, SCR Switch Turns Off With Reverse Bias, Electronics, 38:7, p 88.
