HD44801A80 is a microcomputer intergrated circuit of communication single doors, which is widely used in all kinds of phones.
1. function features
HD44801A80 contains sub-circuits of pulse/two-tone coupling with dialing, key switch signal encoding, electrical long-distance call lock, display driven control circuit and other application circuits.
2. pin functions and data
HD44801A80 is encapsulated in dual in-line package with 42-lead, whose pin functions and data are listed in Table-1.
