The PC Intergrated Circuit of C807-1354 Communication Single Door

Published:2011/5/10 20:40:00 Author:Borg | Keyword: Intergrated Circuit, Communication, Single Door | From:SeekIC

C807一1354 is an PC intergrated circuit of communication single door which is used in wirless phones as the bus master of cell phones. 1.function features C807一1354 intergrated circuits contain control circuits of wireless delivering/receiving,LCD drive, lighting lamps, key switch encoding/decoding, clock shocking, in it, phase-locked loop signal handling, buzzer drive, code generating and conditioning, low voltage test,charging and othe functions. 2.pin functions and relevent data C807—1354 intergrated circuits are packaged with 44 pinnings,whose pin functions and data are listed in Table 1. Table 1 pin functions and data of C807-1354
