Zhonghua saloon car ABS circuit (3)

Published:2011/9/4 20:43:00 Author:TaoXi | Keyword: ZhongHua, saloon car, ABS | From:SeekIC

The ZhongHua saloon car ABS circuit (3) D08-grounding L3-brake shoe attrition indicator light S05-Left front wheel brake shoe attrition sensor S06-Right front wheel brake shoe attrition sensor T5-Engine room right wiring harness and dashboard connector T15-Engine room left wiring harness and dashboard connector T16-dashboard wiring harness and integrated instrument panel plug-in connector U37PA-connection point, in the dashboard wiring harness
