The bridge rectifier demonstration circuit (NE555)

Published:2013/1/28 2:37:00 Author:Ecco | Keyword: bridge rectifier , demonstration | From:SeekIC

The bridge rectifier circuit is the most commonly used AC- DC power conversion circuit. Bridge rectifier demonstration circuit shown in Figure reveals the bridge rectifier circuit, the two sets of rectifier diodes can alternately work. It consists of a pulse generating circuit, current direction control circuit, demonstration circuit and power supply.
