TEAl504 switching power control circuit diagram

Published:2011/8/4 2:14:00 Author:Ecco | Keyword: switching power control | From:SeekIC

TEAl504 new switching power supply control IC produced by Philips, which is the core component to form the separately excited switching power supply, and they are widely used in color television sets, computers and color monitors, and other electrical power supply circuits. TEA1504 integrated circuit includes start-up circuit, switch drive circuit, power supply circuit, oscillation frequency control circuit, power on / off control circuit, switch circuit incentives, and other auxiliary circuits.
