Published:2012/9/16 21:52:00 Author:Ecco | Keyword: Swiss , ML Testakica | From:SeekIC
The Unit is started by hand by revolving the two disks in opposite directions and continues to move without further input. This device has only two moving parts namely the bearing races at the centre of the disk. The disk are made of clear plastic upon which are placed flat a series of fifty blade type steel or aluminium sections equally spaced around the middle sections of each disk. The speed of the revolving disks is about 50 to 60 rpm limited to this by magnetic impulses from the magnetic section on the rim.
