LA7837 Field scanning output IC

Published:2011/9/13 20:18:00 Author:Ecco | Keyword: Field scanning output IC | From:SeekIC

LA7837 field scanning output IC produced by Japan's Sanyo is widely used in domestic and imported color TV. 1. Features and functions LA7837 IC includes field oscillation and sawtooth generator circuit, field excitation and output circuit. The maximum output current is 1.8 AP-P, and the maximum output power is 8W, then the manifold internal block diagram and typical application circuit are shown in Figure 1. 2. pin functions and data LA7837 IC pin functions and data are listed in Table 1-2.
