MC68HCO5C4P-Communication single-chip microcomputer integrated circuit diagram

Published:2011/6/1 22:24:00 Author:leo | Keyword: MC68HCO5C4P-Communication single-chip microcomputer integrated circuit diagram | From:SeekIC

MC68HCO5C4P is a kind of communication single-chip microcomputer integrated circuit made by Motorola which can be applied in wireless telephone and is used as host control chip in cell phone. 1.Function Feature:The integrated circuit MC68HCO5C4P has one more 'P' than MC68HCO5C4. But they have part of different pins and cannot change directly for the same usage.MC68HCO5C4P is improved on the base of MC68HCO5C4. So most of functions of them are similar which can be found in the introduction of MC68HCO5C4 functions. 2.Pin Functions and dataThe integrated circuit MC68HCO5C4P adopts 40-pin package and is used together with MC68HC5PI. All pins function and data of the integrated circuit are shown in the picture bellow.
