Capacitive dimmer switch circuit (2)

Published:2011/6/28 2:35:00 Author:Ecco | Keyword: Capacitive , dimmer switch | From:SeekIC

The circuit described as the chart is the dimmer switch circuit which uses the capacitor discharging principle, and it is suitable for incandescent light, and it has no interference effect on radio, television and other appliances. The principle of the circuit is shown as the chart. The relationship of voltage VE across the lamp and the switch combination is shown as the following table:
