MC13007-Single television small signal processing circuit

Published:2011/7/13 19:42:00 Author:leo | Keyword: Small signal processing circuit, 200 linear circuits | From:SeekIC

MCI3007 is a kind of integrated circuit made by Motorola. It contains 200 linear circuits and 200 logic circuits. It can be used to clear all small signals processing circuit except accompanying sound signals. It contains intermediate frequency amplifier, video detector, video processing circuit, noise control circuit and so on. Its inner circuit diagram and pin functions are shown in the picture. The function of MC13007 has following features: Video detector adopts whole wave detecting circuit. Usually, the common wave detector uses synchronous wave detecting circuit but MC113007 uses balanced diode whole wave detecting circuit. It has multi function video processing circuit. Its oscillator circuit adopts double horizontal frequency mode.
