The e-control injection system circuit of Daewoo Racer

Published:2011/5/21 23:58:00 Author:Borg | Keyword: oil injection system, Daewoo | From:SeekIC

The emission of Racer engine is 1.5L, single top cam shaft of 4 in-line cylinders, the oil supply system is fixed with a TBI throttle body--the central oil injection (single point) system. And on the higher part of the throttle center, there is a multiple jet fulfilling oil injection, and there is a pressure adjuster, idling speed control stepper motor, throttle position sensor, air filter control, oil channel interface, etc. And its size is the same as carburettor.1.oil system consists of oil box, oil pump M3, oil pipe channel, etc.
