SHANGHAI GM Chevrolet（Sail）saloon car automatic transmission circuit diagram(one)

Published:2011/4/21 20:39:00 Author:muriel | Keyword: SHANGHAI GM Chevrolet（Sail）, saloon car , automatic transmission | From:SeekIC

Figure SHANGHAI GM Chevrolet（Sail）saloon car automatic transmission circuit diagram(one) K85 control unit-automatic transmission 806-855P48 sensor-speed, transmission output 831-832S10 shift knob position 806-816P45 sensor-speed, transmission input 836-837U13 valve body 826-836
