MC3359 radiofrequency receiver circuit diagram

Published:2011/9/15 1:44:00 Author:Rebekka | Keyword: radiofrequency receiver | From:SeekIC

Here is the schematic diagram of the MC3359 radiofrequency receiver circuit diagram: MC3359 is the RF receiver circuit, and it can receive 315MHZ, 434MHZ bandwidth, and the IF bandwidth is 500KHZ.
