Golf Bora Comfort System Circuit

Published:2011/7/15 8:34:00 Author:Robert | Keyword: Golf, Bora, Comfort, System | From:SeekIC

The pictures show the Golf Bora comfort system circuit. The first picture shows the driver's side door electronic control unit, driver's side door window lifter, car inner lock switch, window lifter switch, rear door window lifter chain switch. The second picture shows the driver's side door electronic control unit, driver's side central door clock, central door clock indicator lamp, left door warning lamp. The third picture shows the driver's side door electronic control unit, rearview mirror adjustment switch, car external rearview mirror heating switch, rearview mirror folding switch. The fourth picture shows the driver's side door electronic control unit, driver's side door electrical adjustable rearview mirror. The fifth picture shows the front passenger side door electronic control unit, front passenger side door window lister, front passenger side central door lock. The sixth picture shows the front passenger side door electronic control unit, front passenger side door external rearview mirror (electrical adjustment), right car door warning light. And so on.
