Chang an Star SUV 6350B engine control system circuit diagram

Published:2011/10/20 2:33:00 Author:Rebekka | Keyword: Chang an Star SUV, engine control system | From:SeekIC

Changan Star SUV 6350B engine control system circuit diagram is shown as above. 1. Camshaft position sensor 2. Crankshaft position sensor 3. Intake manifold pressure sensor 4. Throttle position sensor 5. Engine coolant temperature sensor 6. Intake air temperature sensor 7.8. Empty 9. Oxygen sensor 10. Speed sensor 11 . heater switch 12.Air conditioning control module 13.Light switch 14.In light switch 16.Data transmission connector 17.ABS electronic control unit 18. Tachometer 20.2 19.No1 fuel injector 20. No 2 fuel injectors fuel injectors 22.4 21.No.3 No. 24-valve fuel injectors 23.EGR. Canister magnetic valve 24-1. Fuel pressure regulator vacuum switch valve 25. idle air control valve 26. radiator fan relay 27. radiator fan motor 28. diagnostic interface 29. pump relay 30. fuel pump 31. fault indicator 32. ignition coil assembly 33. ignition ring assembly 34. ignition switch 35. main relay 36. starter solenoid switch 37. accumulator 38. Engine Electronic Control Unit
