1/86400Hz Pulse Generator Circuit

Published:2011/4/22 21:40:00 Author:Sue | Keyword: Pulse, Generator, 1/86400Hz | From:SeekIC

As illustrated, in the circuit it is able to input a clock pulse of 1Hz every 24 hours, which can be generated by digital clock. It can offer the a.m. or p.m. instructions for those without this function, or to be used to preset the date of digital calendars. Also it can serve as a reliable alarm trigger at a particular time.
