25_75_KC_FREQUENCY_MODULATOR

Published:2009/7/24 4:50:00 Author:Jessie | From:SeekIC

Frequency changes are linear within 1% with changes in input voltage. Circuit can easily be modified for other frequency ranges. Designed for use with magnetic tape recorders. Cf is primary frequency-determining element.-P. S. Bengston, Frequency Modulator Covers 25.75 Kc, Electronics, 31:31, p 100-106.
