Two-channel audio power amplifier integrated circuit diagram

Published:2011/5/12 1:55:00 Author:Ecco | Keyword: Two-channel , audio , power amplifier, integrated circuit | From:SeekIC

TDA2007 is a dual audio power amplifier integrated circuit produced by Philips, which is widely used in television audio, home audio, multimedia audio, computer audio, car audio and so on. 1.The featuresand functionsThe internal circuit of TDA2007 integrated circuit is mainly composed of two identical audio power amplifier circuit, overheat and over current, short circuit protection circuit. 2. Pin functions and data TDA2007 IC uses 9-pin single in-line package, the pin functions and data are listed in Table 1. Table 1 shows TDA2007 integrated circuit pin functions and data.
