SCR_IMPROVES_SCHMITT_TRIGGER_STABILITY

Published:2009/7/21 8:08:00 Author:Jessie | From:SeekIC

Input signals to 200 kc give consistent triggering over wide range of temperature, source impedance, and input impedance, and hysteresis is reduced by order of 10.-M.Schmidt, Improved Schmitt Trigger Uses SCR, Electronics, 36:17, p 68.
