POWER_FLIP_FLOP

Published:2009/7/23 21:31:00 Author:Jessie | From:SeekIC

Delivers square wave output pulse of 1 amp when pnpn unit is triggered on by low-level positive pulse applied to its base.-J. B. Hangstefer and L. H. Dixon, Jr., Triggered Bistable Semiconductor Circuits, Electronics, 32:35, p 58-60.
