1. Function featuresMN1874033TNW consists of CPU, clock oscillating circuit, reset control circuit, I2C general control circuit, screen displayed letter generating and processing circuit, and other control and affiliated function circuits, etc.2.pin functions and data MN1874033TNW is in 64-pin dual line package, whose internal circuit, pin functions and signal flow is shown in the figure, and its pin function introduction is in the table.
The internal circuit, pin functions and signal flow of MN1874033TNW
