MN152810TTD5 single chip microcomputer integrated circuit

Published:2011/6/8 1:58:00 Author:Christina | Keyword: single chip, microcomputer, integrated circuit | From:SeekIC

The MN152810TTD5 is designed as one kind of single chip microcomputer integrated circuit that is produced by the Panasonic corporation, and it can be used in the Konka and TCL color TVs. 1.Features The MN152810TTD5 integrated circuit is composed of the central processing unit (CPU), the clock oscillating circuit, the reset control circuit, the key instruction decoder circuit, the I2C bus control circuit, the remote control command signal processing circuit, the screen display circuit, the audio adjusting control circuit, the integrated converter circuit and other control and auxiliary function circuits. 2.Pin functions and data The MN152810TTD5 is in the 52-pin dual in-line package, the internal circuit block diagram and the signal flow are as shown in the figure, the pin-letter code and the data is as shown in the table. The internal circuit block diagram and the signal flow of the MN152810TTD5 The pin-letter code and the data of the MN152810TTD5
