MC1748C operational amplifier and its pin main characteristics

Published:2013/1/15 1:50:00 Author:Ecco | Keyword: operational amplifier, pin main characteristics | From:SeekIC

It has short circuit protection; the MC1741 has no compensation; CMRR = 90dB; when it has unity gain, it just needs a 30pF compensation capacitor; working power is ± 15V; PSRR is greater than 75dB; output impedance is 75Ω; common-mode input voltage is ± 13V.
