Integrated circuit inside circuit box circuit

Published:2011/9/14 21:01:00 Author:John | Keyword: Integrated circuit, inside circuit | From:SeekIC

Features LM331 integrated circuit is a precision frequency - voltage (also voltage - frequency) converting circuit. It includes power switch circuit, precision current source, reference power, timing comparator, RS flip-flop, input comparator, protection circuit and some other auxiliary circuit. The inside circuit box circuit is just as shown.
