ICL8021 programmable operational amplifier and its pin main characteristics

Published:2013/1/4 2:18:00 Author:Ecco | Keyword: programmable operational amplifier, pin main characteristics | From:SeekIC

2mV Input offset voltage; 5μV /℃ temperature drift; 5nA bias current; Gain Bandwidth GB = 370kHz; 160mV/μs conversion rate; 30μA current consumption; ± 1 to ± 18V power supply; ± 15V differential-mode input voltage; ± 15V common-mode input voltage; 300mW allows loss.
