TEA5170 -Switch power source thick film integrated circuit

Published:2011/7/10 6:02:00 Author:leo | Keyword: Switch power source , thick film | From:SeekIC

TEA5170 is a kind of switch power source thick film integrated circuit produced by Thomson Company which is widely used in Toshiba 2500XH, MCI5A, Samsung C56229Z, Kangyi 66mm, Mud an 64C1, Jinxing C6418, Feiyue FY7403, Xihu C2918 and other color television. 1.Function features:TEA5170 contains power supply control circuit, drive pulse circuit, oscillator circuit, difference signal processing circuit and other circuits. 2.Pin functions and data:TEA5170 pin functions and other related data are shown in the picture.
