AN7108-the integrated reproducing circuit of single door stereo

Published:2011/5/18 8:35:00 Author:Borg | Keyword: reproducing circuit, single door stereo | From:SeekIC

AN7108 is in 16-lead dual in-line package, which is formed by two same channels, and each channel consists of preamplifier, volume control and headphone drive power amplifier circuit. The V ref wave filter and bias circuit in the circuit have good ripple contain factors, and they can normally work without any adjustment. Besides, just a potentiometer could control the electric pressure controlled stereo volume, and it overcomes the frictions noise, the pressure controlled amplifier consists of drives.
