6C33C-B produced 10W single-ended amplifier circuit diagram

Published:2013/2/18 0:57:00 Author:Ecco | Keyword: 10W, single-ended amplifier | From:SeekIC

6C33C-B is a low internal resistance, linear tri-polar bile. Filament voltage is 6.3V/12.6V, filament current is 6.6A/3.3A, screen consumption is 60W, 26 to 40mA / V, transconductance amplification factor is 24, the single-ended amplifier with 6C33C-B has mellow and sweet tone. The circuit is shown as figure, the former uses high μ tube 6SQ7GT for voltage amplification to promote with 6C5P as cathode follower.
