50-Watt Amplifier

Published:2012/10/12 22:53:00 Author:muriel | Keyword: 50-Watt, Amplifier | From:SeekIC

This is a handy, easy to build general purpose 50 watt amp. The amp has an input for a radio, TV, stereo or other line level device. It also has a phono input for a record player, guitar, microphone or other un-amplified source. With the addition of a low pass filter at the input, it makes a great amp for a small subwoofer.
