455_kHz_IF_AMP_FOR_15_V_OPERATION

Published:2009/6/18 2:11:00 Author:May | From:SeekIC

The ZN416E can be configured as a simple 455-kHz IF amplifier. In this case, the circuit's center and bandwidth are set by RES1 (a Murata CSB455E ceramic resonator).
