455_kHz_IF_AMPLIFIER

Published:2009/6/18 2:01:00 Author:May | From:SeekIC

Up to bU dB of gam at 455 kHz is available with the MC1350P. RES1 is a ceramic resonator, LC, or crustal filter. Keep the leads to pins,1, 2, 3, and 7 short.
